High Performance Coatings
PrimeLiner EM – Epoxy Mortar
PrimeLiner EM is the industry leader in anti-microbial epoxy mortar technology. The liner contains a broad spectrum anti-microbial that that protects the material from mold, mildew and bacterial growth*. Product is also formulated to be extremely chemically resistant, (almost 1,000 times more resistant to chemical environments than Calcium Aluminate based cements). The cross link of the epoxy matrix creates a dense liner that protects substrate from the harsh environment typically found in waste water infrastructure.
Advantages
- Increases concrete corrosion resistance dramatically
- Maintainable, repairable system
- Easy application by hand, or spray pump (See below for details)
- Excellent solution for damp environments
- Single coat application (Self Priming)
- Interior or exterior applications
- Excellent economical solution
- Excellent adhesion of topcoats (Polyurea and Epoxy)
Download the PrimeLiner EM (Epoxy Mortar) Data Sheet
PrimeLiner Fiber Reinforced Polymer
PrimeLiner FRP: An advanced next generation, 100% solids, ultra high-build, high-strength structural Fiber Reinforced Polymer (FRP) for the protection of steel and concrete. Designed to be used as a standalone structural liner or in conjunction with other PrimeLiner repair materials. Suitable for use in all stages in the wastewater collection and processing system. Exhibits excellent hydrostatic pressure chemical and abrasion resistance making it ideal for these harsh environments.
Typical Uses:
PrimeLiner FRP is designed to protect, line and rehabilitate sanitary sewer collection system assets, and other underground structures. Ideal for structures in contact with extreme H2S and in need of aggressive I&I mitigation.
Application:
PrimeLiner FRP is designed to be applied easily by hand trowel or sprayed on by heat-ed, plural component spray pump.
Download the PrimeLiner FRP (Fiber Reinforced Polymer) Data Sheet
High Performance Coatings
- Use to fill, repair, patch, and/or to resurface and line (all-in-one-shot)
- Eliminates infiltration/exfiltration (sealed system – NOT cementitious, no porosity/permeability)
- No investment in heavy equipment (simply mix and trowel-apply)
- Easy-to-mix, easy-to-apply, premeasured kits
- Minimal downtime, rapid return to service
- No need for sand blasting (water blast instead)
- Ultra-high build, no sag (apply up to half-inch per pass)
- Structural (16,000 psi compressive strength)
- Self-priming, highly adhesive and forgiving
- Moisture tolerant (can even cure in wet conditions while in service)
- Repairable, ties back into itself indefinitely
- Chemical resistant, including H2S
- Proven (over 20 years at Miami-Dade Water & Sewer)
- Holds back roots
- Tolerant to ground movement, and traffic vibration
- Environmentally friendly, no VOCs, no solvents
CPP™
Proven
Probably the most important aspect of any coating is its proven application and effectiveness in different environments. CPP™ has been used throughout Miami-Dade Water & Sewer´s fluid flow processing and collection structures. It has proven itself since 1990 with excellent results in some of the most severe environments known. (i.e. Closed UNOX (O2) Trains).
All-in-one-shot, Structural Liner/Coating
CPP™ when used as coating/liner, can resurface, rebuild, and protect all-in-one-shot as a sealed system preventing infiltration and exfiltration, and combating the effects of corrosion. Many times corrosion can deteriorate concrete and risk the integrity of the structure. In addition to the aforementioned, CPP™ performs exceptionally over rebar and for repairs to areas on concern as it boasts up to 16,000 psi compressive strength, making it a structural fix.
Easy Mix
What this means to the applicator is that it is easy to mix, no complicated mix ratio, meaning less room for human error, higher installation success. Kits are either 1-to-1 or available in a premeasured unit.
Moisture and Wet Tolerant (can even cure underwater)
Wet tolerant is actually an understatement for CPP™ because CPP™can adhere and cure underwater (used to repair seawalls underwater). This is a unique quality that is needed and used in the water and wastewater environments. Very few systems can withstand high levels of moisture without failing. The CPP™ performs well in humid environments (especially found in Florida closed environment structures) such as closed tanks, pipes, and underground structures. It´s great to use, if needed, while some structures are in service, as it can cure without any effects exposed to splash or even overflow, as long as the flow is not aggressive or pressurized.
Adhesion
Adhesion is one of the most important features of any coating in preventing corrosion for the long-term. CPP™ is self-priming and has among the best adhesive properties ever seen by Epoxytec. CPP™ adheres to most surfaces, often outperforming even to mistaken imperfect surfaces or unknowns, and with substrate breaking bond strength on concrete (greater than the cohesive strength of the concrete itself).
Forgiving & Surface Tolerant
This is where CPPTM shines. CPP™ has been proven to be extremely surface friendly. The coating can often bridge the gap when unknown environmental control limitations occur (often happening unintentionally), the coating is able to be applied and outperform better than typical surface-sensitive competitive products.
Ease of Application
CPP™ can be simply applied by trowel (or an optional spray version) when other coatings require expensive application systems from $20,000 to over $100,000 per sprayer.
High Build (up to 1 1/2″ in a single pass)
What this means to the applicator is that they can apply a thick coating for the first time and eliminate multiple coatings costing time and labor, which results in costing money.
Durable & Resistant
CPP™ does not act like a typical coating, rather it can be better categorized as a permanent barrier, shell, or patch. It does not fail due to delamination like a thin or brittle coating could. It can take chemical attack, gaseous or microbial attack, hydrostatic pressure, rooting pressure, vibration and good impact, etc.
Easily Repairable
CPP™ is a system that can be recoated, repaired, and touched-up without complicated preparation – simple cleaning and degreasing is all that is needed. This makes having a preventive maintenance program feasible with high life-cycle expectations, usually just requiring simple visual inspection and touch-up (often just with a brush) when needed. Doing this can extend the life-expectancy for decades with minimal investment and uncomplicated application.
Uroflex™
Proven
Probably the most important aspect of any coating is its proven application and effectiveness in different environments. Uroflex™ has been used in over 2-million sq. ft. with Miami-Dade Water and Sewer alone. It has proven itself over a 20 year period with excellent results in some of the most severe environments known. (i.e. Closed Unox (O2) Trains with less than 1% touch-up after 7 – 10 years).
1-to-1 Mix Ratio
What this means to the applicator is that it is easy to mix, no complicated mix ratio, meaning less room for human error, higher installation success.
Flexible, with 38% elongation
Using a proprietary blend, urethane-modified-epoxy, the product can withstand expansion and contraction, as well as vibration from the substrate without cracking or splitting. 38% elongation makes the product more tolerant of tank movement, steel, and concrete expansion/contraction and hairline cracking, traffic and ground movement, etc.
Moisture Tolerant (up to 90% moisture in concrete)
Very few protective coatings can withstand this the often high levels of moisture without failing. The coating also performs well in humid environments (especially found in the S. Florida closed environment structures) such as closed tanks, pipes, and underground structures.
Adhesion
Adhesion is one of the most important features of any coating in preventing corrosion for the long-term. Uroflex™ is self-priming and has excellent adhesion up to 2,000 psi on steel and substrate breaking bond strength on concrete (greater than the cohesive strength of the concrete itself).
Forgiving & Surface Tolerant
This is where Uroflex™ shines. Uroflex™ has been proven to be surface friendly. The coating can often bridge the gap when unknown environmental control limitations occur (often happening unintentionally), the coating is able to be applied and outperform better than typical surface-sensitive competitive products.
Ease of Application
Uroflex™ can be applied by brush, roller or spray when other coatings require expensive application systems from $20,000 to over $100,000 per sprayer.
Self Leveling & High Gloss
This is important for several reasons. The urethane modification to the epoxy makes the coating UV tolerant (great for above-ground structures). The high gloss finish of Uroflex™ is easy to clean, keeping offending buildup and other contaminants from damaging the coating. Its self-leveling capabilities allow the coating to “wet” the surface properly and fill bugholes and cracks adequately. Also the urethane crosslinking provides the Uroflex™ increased impermeability characteristics, making it a long-lasting, durable sealed system.
High Build (up to 60 mils in a single pass)
What this means to the applicator is that they can apply a thick coating for the first time and eliminate multiple coatings costing time and labor, which results in costing money.
Durable & Resistant
While Uroflex™ has proven itself at as little as 30 mils in extreme environments, at 50 – 60 mils has proven to be as effective.
Repairable
Uroflex™ coating is a system that can be recoated, repaired, and touched-up without complicated preparation – simple cleaning and degreasing are all that is needed. This makes having a preventive maintenance program feasible with high life-cycle expectations, usually just requiring simple visual inspection and touch-up (often just with a brush) when needed. Doing this can extend the life-expectancy for decades with minimal investment and uncomplicated application. Contact us today to learn more about our top-quality trenchless and pipeline equipment.
